6-Layer Soft-Hard Combined PCB for Electronic Scanners Suppliers, Manufacturers

Product Description

Product Overview

The 6-layer soft-hard combined PCB for electronic scanners is a high-performance circuit board specifically designed for handheld scanning devices. This product combines the advantages of rigid boards (FR-4) and flexible circuit boards (FCCL), enabling high-density wiring and complex electronic functions within a limited space while ensuring the product's lightweight and flexible nature. Designed with a focus on high precision, high reliability, and anti-interference capabilities, it can meet the usage requirements of handheld scanners in various environments, providing users with a stable and efficient scanning experience.

Product Features

1. Soft-Hard Combined Design: The combination of rigid boards (FR-4) and flexible circuit boards (FCCL) balances stability and flexibility, making it suitable for the compact structural design of handheld devices.

2. High-Precision Wiring: With a minimum via size of 0.35mm and line width/line spacing of 0.8mm/0.5mm, it supports high-density wiring to meet complex functional requirements.

3. Strong Anti-Interference Capability: Immersion gold surface treatment enhances signal integrity, reducing electromagnetic interference to ensure the high precision and stability of the scanner.

4. High Durability: The immersion gold process improves the wear resistance and oxidation resistance of the gold fingers, extending the product's service life.

5. Aesthetic and Practical Design: Black solder mask with white lettering not only looks aesthetically pleasing but also effectively protects the circuitry from oxidation and contamination.

Technical Specifications

Number of layers	6 layers	Minimum line width/line spacing	0.8/0.5mm
Raw material	FR-4, FCCL	Ink color	black oil white text
Thickness	0.6mm	Surface treatment method	immersion gold
Copper thickness(Inner/Outer)	1OZ/1OZ	/	/

Application Areas

Handheld Scanners: Suitable for assembly in various handheld scanning devices, such as logistics scanners, medical imaging scanners, and industrial inspection scanners.

Mobile Office Equipment: Such as portable document scanners, meeting the needs of mobile office work.

Smart Inspection Equipment: Used in the electronic control systems of smart inspection devices, providing high-precision signal transmission and processing.

Consumer Electronic Devices: Such as portable e-readers and smart handheld devices, offering compact circuit solutions.

Special Production Process

1. Soft-Hard Combined Technology: Advanced soft-hard combined technology seamlessly connects rigid and flexible circuit boards, ensuring the stability and flexibility of the circuit.

2. High-Precision Drilling Process: Minimum via size of 0.35mm ensures high-precision drilling to meet complex wiring needs.

3. Immersion Gold Surface Treatment: Using immersion gold process to enhance the conductivity, wear resistance, and oxidation resistance of the gold fingers, extending the service life.

4. Anti-Interference Design: Optimized wiring and material selection reduce electromagnetic interference, ensuring the high precision and stability of the scanner.

5. Strict Quality Inspection: Each PCB undergoes strict visual inspection, electrical performance testing, and reliability testing to ensure high product quality and stability.

Product Summary

The 6-layer soft-hard combined PCB for electronic scanners, with its unique soft-hard combined design, high-precision wiring capabilities, and anti-interference performance, is the ideal choice for handheld scanning devices. It not only meets the needs of complex functions but also ensures the product's lightweight, durability, and high reliability, providing users with a stable and efficient scanning experience. Whether in logistics, medical, or industrial inspection fields, this PCB offers reliable electronic support, facilitating product innovation and development.
